OptiX RTN 310 Outdoor Wireless Microwave F133026BLA Code 52450412 for Hills and Forests

Model Number : RTN 310

Type : Other

Place of Origin : Guangdong, China

Brand Name : HW

Use : Sea surface, land, hills and forests, islands

Warranty Time : 1 year

Network : Wireless Lan, TCP, Ip, wifi, IP microwave

Product name : RTN 310AX

Frequency band : 6 ~ 42 GHz

Channel spacing : 3.5/ 7/14/28/40/56/112 MHz

Radio-frequency direction : 12

TDM crossover capacity : 32*32 VC-4

Power supply : -38.4 V~-57.6 V

Network layer : Suitable for: access layer and aggregation layer

Channel bandwidth : Determine based on ODU bandwidth

Usage : Wireless long-distance transmission

Feature : High efficiency/High performance

MOQ : 2 sets

Price : $1,000.00 - $1,500.00/sets

Contact Now

PRODUCT DESCRIPTION
OptiX RTN 310 Outdoor Wireless Microwave F133026BLA Code 52450412 for Hills and Forests
Long Range Microwave Transmission Equipment Assembly RTN 310 Series
The Huawei E-Band microwave product series (RTN310-13G) has abundant spectrum resources and low cost. These products have a super large transmission capacity of up to 10Gbit/s, suitable for high bandwidth IP service aggregation. The full outdoor weather resistance and simplified operation and maintenance functions make this product series very suitable for dense deployment in urban areas, and meet the requirements of broadband wireless transmission in various scenarios such as enterprise dedicated line interconnection and ISP fixed broadband return.
TECHNICAL SPECIFICATION
Specifications
RTN 310
RTN 380AX(DC+P&E)
RTN 380AXH
Frequency
71~76/81~86GHz
Channel Bandwidth
62.5~/1000 MHz
62.5~2000 MHz
62.5~2000 MHz
Max. Throughput
7.5Gbps
10Gbps
10Gbps
Modulations Schemes
BPSK~512QAM
BPSK~1024QAM
BPSK~1024QAM
Service Interface
2*10GE(SFP)+2*GEe
3*10GE(SFP)+1*GEe
4*10GE(SFP)+1*GEe
Tx Power @QPSK
18 dBm
18 dBm
26 dBm
Super Dual Band
Yes
Yes
Yes
L3 VPN
No
Yes
Yes
eCPRI Support
Not support
Support 10G eCPRI
Support 10G eCPRI
XPIC Support
Not support
Yes
Yes
Power Consumption
39W (typical)
49W (typical)
69W (typical)
Dimensions
265*285*73mm
265*320*73 mm
265*320*83 mm
Power Supply
P&E
DC + P&E with Redundancy
DC + P&E with Redundancy
